Takeoff Weight
249.9 g
Dimensions
Folded (without propellers): 157×95×68 mm (L×W×H)
Unfolded (with propellers): 304×380×91 mm (L×W×H)
Max Ascent Speed
10 m/s (S Mode)
5 m/s (N Mode)
5 m/s (C Mode)
Max Descent Speed
8 m/s (S Mode, using DJI Mini 5 Pro Intelligent Flight Battery Plus*)
6 m/s (S Mode, using DJI Mini 5 Pro Intelligent Flight Battery)
5 m/s (N Mode)
5 m/s (C Mode)
Max Horizontal Speed
19 m/s* (S Mode, using DJI Mini 5 Pro Intelligent Flight Battery Plus**)
18 m/s* (S Mode, using DJI Mini 5 Pro Intelligent Flight Battery)
15 m/s*** (tracking status)
Max Takeoff Altitude
6000 m (using DJI Mini 5 Pro Intelligent Flight Battery)
4500 m (using DJI Mini 5 Pro Intelligent Flight Battery Plus*)
2000 m (using DJI Mini 5 Pro Quick-Release 360° Propeller Guard (with Integrated Propellers))
Max Flight Time
36 minutes (using DJI Mini 5 Pro Intelligent Flight Battery)
52 minutes (using DJI Mini 5 Pro Intelligent Flight Battery Plus*)
Typical Flight Time
21 minutes (using DJI Mini 5 Pro Intelligent Flight Battery)
33 minutes (using DJI Mini 5 Pro Intelligent Flight Battery Plus*)
Max Flight Distance
21 km (using DJI Mini 5 Pro Intelligent Flight Battery)
32 km (using DJI Mini 5 Pro Intelligent Flight Battery Plus*)
Max Wind Speed Resistance
12 m/s
Max Pitch Angle
38°
Operating Temperature
-10° to 40° C (14° to 104° F)
Global Navigation Satellite System
GPS + Galileo + BeiDou
Hovering Accuracy Range
Vertical:
±0.1 m (with vision positioning)
±0.5 m (with satellite positioning)
Horizontal:
±0.3 m (with vision positioning)
±0.5 m (with satellite positioning)
Internal Storage
42 GB
Class
C0 (EU)
Camera
Image Sensor
1-inch CMOS, 50MP Effective Pixels
Lens
FOV: 84°
Format Equivalent: 24 mm
Aperture: f/1.8
Focus: 0.5 m to ∞
ISO Range
Video
Normal:
100-12800 (Normal)
100-3200 (D-Log M)
100-3200 (HLG)
Slow Motion:
100-6400 (Normal)
100-3200 (D-Log M)
100-3200 (HLG)
100-6400 (12 MP)
100-3200 (50 MP)
Shutter Speed
12MP Photo: 1/8000-2 s (2.5-8 s for simulated long exposure)
50MP Photo: 1/8000-2 s
Max Image Size
8192×6144
Still Photography Modes
Single Shot: 12 MP and 50 MP
Burst Shooting: 12 MP, 3/5/7 frames; 50 MP, 3/5 frames
Automatic Exposure Bracketing (AEB): 12 MP, 3/5/7 frames; 50 MP, 3/5 frames at 0.7 EV step
Timed: 12 MP, 2/3/5/7/10/15/20/30/60 s; 50 MP, 5/7/10/15/20/30/60 s
Photo Format
JPEG/DNG (RAW)
Video Resolution
H.264/H.265
4K: 3840×2160@24/25/30/48/50/60/120*fps
FHD: 1920×1080@24/25/30/48/50/60/120*/240*fps
Video Format
MP4 (MPEG-4 AVC/H.264, HEVC/H.265)
Max Video Bitrate
H.264/H.265: 130 Mbps
Supported File System
exFAT
Color Mode and Sampling Method
Normal (FHD):
8-bit 4:2:0 (H.264)
Normal (FHD/4K):
10-bit 4:2:0 (H.265)
HLG/D-Log M:
10-bit 4:2:0 (H.265)
Digital Zoom
12MP Photo: 1-3x
4K: 1-3x
FHD: 1-4x
Gimbal
Stabilization
3-axis mechanical gimbal (tilt, roll, pan)
Mechanical Range
Tilt: -135° to 80°
Roll: -230° to 95°
Pan: -25° to 25°
Controllable Range
Tilt: -90° to 55°
Roll: -180° to 45°
Max Control Speed (tilt)
100°/s
Angular Vibration Range
±0.005°
Sensing
Sensing Type
Omnidirectional binocular vision system, supplemented with forward-facing LiDAR and an infrared sensor at the bottom of the aircraft
Forward
Measurement Range: 0.5-18 m
Detection Range: 0.5-200 m
Effective Sensing Speed: Flight Speed ≤ 15 m/s
FOV: Horizontal 90°, Vertical 72°
Backward
Measurement Range: 0.5-18 m
Effective Sensing Speed: Flight Speed ≤ 14 m/s
FOV: Horizontal 90°, Vertical 72°
Lateral
Measurement Range: 0.5-12 m
Effective Sensing Speed: Flight Speed ≤ 14 m/s
FOV: Horizontal 90°, Vertical 72°
Upward
Measurement Range: 0.5-18 m
Effective Sensing Speed: Flight Speed ≤ 6 m/s
FOV: Front and Back 72°, Left and Right 90°
Downward
Measurement Range: 0.3-14 m
Effective Sensing Speed: Flight Speed ≤ 6 m/s
FOV: Front and Back 106°, Left and Right 90°
Operating Environment
Forward, Backward, Left, Right, and Upward:
Surfaces with discernible patterns and adequate lighting (lux > 1)
Downward:
Surfaces with discernible patterns, diffuse reflectivity > 20% (e.g., walls, trees, people), and adequate lighting (lux > 1)
3D Infrared Sensor
Forward-Facing LiDAR
Measurement Range (nighttime): 0.5-25 m (reflectivity > 10%)
FOV: Up and Down 60°, Left and Right 60°
Downward-Facing Infrared Sensor
Measurement Range: 0.3-8 m (reflectivity > 10%)
FOV: Front and Back 60°, Left and Right 60°
Video Transmission
Video Transmission System
O4+
Live View Quality
Remote Controller:
1080p/30fps, 1080p/60fps
Operating Frequency
2.400-2.4835 GHz
5.170-5.250 GHz
5.725-5.850 GHz
Transmitter Power (EIRP)
2.4 GHz:
< 33 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)
5.1 GHz:
< 23 dBm (CE)
5.8 GHz:
< 33 dBm (FCC)
< 30 dBm (SRRC)
< 14 dBm (CE)
Max Transmission Distance (unobstructed, free of interference)
FCC: 20 km
CE: 10 km
SRRC: 10 km
MIC: 10 km
Max Transmission Distance (unobstructed, with interference)
Strong Interference: Urban landscape, approx. 1.5-4 km
Medium Interference: Suburban landscape, approx. 4-10 km
Low Interference: Suburb/Seaside, approx. 10-20 km
Max Transmission Distance (obstructed, with interference)
Low Interference and Obstructed by Buildings: Approx. 0-0.7 km
Low Interference and Obstructed by Trees: Approx. 0.7-4.5 km
Max Download Speed
O4+:
10 MB/s (with DJI RC-N3 Remote Controller)
10 MB/s (with DJI RC 2)
Wi-Fi 6: Up to 100 MB/s*
Lowest Latency
Aircraft + Remote Controller: Approx. 120 ms
Antenna
4 antennas, 2T4R
Wi-Fi
Protocol
802.11 a/b/g/n/ac/ax
Operating Frequency
2.400-2.4835 GHz
5.725-5.850 GHz
Transmitter Power (EIRP)
2.4 GHz:
< 20 dBm (FCC/CE/SRRC/MIC)
5.8 GHz:
< 26 dBm (FCC/SRRC)
< 14 dBm (CE)
Bluetooth
Protocol
Bluetooth 5.4
Operating Frequency
2.400-2.4835 GHz
Transmitter Power (EIRP)
< 10 dBm
Battery
Capacity
DJI Mini 5 Pro Intelligent Flight Battery: 2788 mAh
DJI Mini 5 Pro Intelligent Flight Battery Plus*: 4680 mAh
Weight
DJI Mini 5 Pro Intelligent Flight Battery: approx. 71.2 g
DJI Mini 5 Pro Intelligent Flight Battery Plus*: approx. 117 g
Nominal Voltage
DJI Mini 5 Pro Intelligent Flight Battery: 7 V
DJI Mini 5 Pro Intelligent Flight Battery Plus*: 7.16 V
Max Charging Voltage
DJI Mini 5 Pro Intelligent Flight Battery: 8.6 V
DJI Mini 5 Pro Intelligent Flight Battery Plus*: 8.6 V
Battery Type
Li-ion
Chemical System
LiNiMnCoO2
Energy
DJI Mini 5 Pro Intelligent Flight Battery: 19.52 Wh
DJI Mini 5 Pro Intelligent Flight Battery Plus*: 33.51 Wh
Charging Temperature
5° to 40° C (41° to 104° F)
Charging Time
DJI Mini 5 Pro Intelligent Flight Battery:
1 battery can be fully charged in approx. 69 minutes by charging through the drone using the DJI 65W Portable Charger.
1 battery can be fully charged in approx. 46 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.
3 batteries can be fully charged in approx. 115 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.
DJI Mini 5 Pro Intelligent Flight Battery Plus:
1 battery can be fully charged in approx. 94 minutes by charging through the drone using the DJI 65W Portable Charger.
1 battery can be fully charged in approx. 56 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.
3 batteries can be fully charged in approx. 193 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.
Battery Charging Hub
Input
USB-C: 5-15 V, max 4.3 A
Output
Battery Port: 5-15 V, max 2 A
Charging Type
DJI Mini 5 Pro Intelligent Flight Battery: Two batteries charged in parallel
DJI Mini 5 Pro Intelligent Flight Battery Plus*: Three batteries charged in sequence
Compatibility
DJI Mini 5 Pro Intelligent Flight Battery
DJI Mini 5 Pro Intelligent Flight Battery Plus
